NGK Marine Spark Plugs: Everything You Need to Know
|
Welcome to our comprehensive guide on NGK marine spark plugs. Learn everything you need to know about marine spark plugs, including types, parts, and the importance of regular replacement. Explore our NGK marine spark plug charts to find the right spark plug for your boat's engine. Marine spark plugs are a critical component of your boat's engine. They are responsible for igniting the fuel-air mixture in the combustion chamber, which is what ultimately produces the power that drives your boat. View our outboard motor spark plugs charts below to find the right spark plug for your motor: |
Types of NGK Marine Spark Plugs
NGK marine spark plugs come in a variety of types, including:
- Standard spark plugs: These are the most common type of marine spark plug. They are made with a copper core and a nickel alloy shell.
- Platinum spark plugs: These spark plugs have a platinum tip, which makes them more durable and resistant to corrosion.
- Iridium spark plugs: These spark plugs have an iridium tip, which makes them even more durable and resistant to corrosion.
Parts of a Spark Plug
|
|
A spark plug is a relatively simple device, but it is made up of several important parts:The Importance of Replacing Your Spark Plugs
Spark plugs wear out over time, and they need to be replaced regularly. The recommended replacement interval for marine spark plugs is typically every 100 hours or 24 months. However, if you operate your boat in harsh conditions, you may need to replace your spark plugs more often.
Symptoms of Bad Spark Plugs
There are a few signs that your spark plugs may be bad, including:
- Engine misfires
- Poor fuel economy
- Rough idle
- Engine hesitation
- Black smoke from the exhaust
Marine Spark Plug Cross Reference Chart
| Champion Part # | NGK Part # |
| L6VC | BUZ8H |
| L76V | BUHW |
| L77JC4 | B7HS-10 |
| L78C | B7HS |
| L78V | BUHW-2 |
| L78YC | BP7HS |
| L82C | B8HS |
| QC10PEP | PZFR6H |
| QC10PEPB | IZFR6N-E |
| QC12PEP | IZFR6N-E |
| QC12PEPA | PZFR6H |
| QC12PEPB | IZFR6N-E |
| QL16V | BUHXW-1 |
| QL76V | BUZHW |
| QL77CC | BR8HS |
| QL77JC4 | BZ7HS-10 |
| QL78C | BR9HS-10 |
| QL78V | BUZHW-2 |
| QL78YC | BPZ8H-N-10 |
| QL78YC | BPZ8HS-10 |
| QL82C | BR6HS |
| QL82YC | BPR7HS |
| QL86C | BR6HS |
| QL87YC | BPR6HS |
| RP10HC | DR6HS |
| UL77V | BUHXW-1 |
| XC12PEPB | PZFR6F-11 |
| AC-Delco Part # | NGK Part # |
| 41-932 | PZTR5A-15 |
| 41-983 | PTR4B-15 |
| 41-985 | IZTR5B11 |
| MR42LTS | BPR6EFS |
| MR43LTS | TR5 |
| MR43T | BR6FS |
| MR44T | YR5 |
Outboard Motor Spark Plug Charts
The following tables provide a chart of NGK marine spark plugs for outboard manufacturers and engine models. You can use this chart to find the correct spark plug for your boat's engine.
| Make | Model | Type | Year | Gap | Standard | Resistor |
| Evinrude | 1.6 | 1.6 L 115-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 1.8 | 1.8 L 140-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 2 | 1975-1980 | 0.7mm (.028") | B6S | ||
| Evinrude | 2.6 | 2.6 L 190-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 2.7 | 2.7 L 225-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 3.6 | 3.6 L 275-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 4 | CDI | 1987- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Evinrude | 4 | MAG | 1987- | 0.6mm (.024") | B6HS | BR6HS |
| Evinrude | 4 | 1977-1980 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 4 | 1981-1986 | 0.6mm (.024") | B6HS | BR6HS | |
| Evinrude | 4.5 | 1979-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 6 | 1978-1979 | 0 | BUHW2 | ||
| Evinrude | 6 | 1984-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 7.5 | 1980-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 8 | 1984-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 9.9 | SAIL DRIVE | 1978-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Evinrude | 9.9 | 1978-1979 | 0 | BUHW2 | ||
| Evinrude | 9.9 | 1980-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 10 | COMMERCIAL | 1981-1982 | 0 | BUHW2 | |
| Evinrude | 14 | COMMERCIAL | 1981- | 0 | BUHW2 | |
| Evinrude | 15 | SAIL DRIVE | 1981-1984 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Evinrude | 15 | 1978-1979 | 0 | BUHW2 | ||
| Evinrude | 15 | 1980-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 20 | 1985-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 25 | 1978-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 25 | 2003-2005 | 1.0mm (.040") | BPZ8HS10 | ||
| Evinrude | 28 | 1987- | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 30 | 1984-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 35 | 1977-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 40 | COMMERCIAL | 1982- | 0.7mm (.028") | B7HS | BR7HS |
| Evinrude | 40 | COMMERCIAL | 1984-1987 | 0 | BUHW2 | |
| Evinrude | 40 | 1981-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 40 | 1982- | 0.7mm (.028") | B7HS | BR7HS | |
| Evinrude | 40 | 2004-2005 | 0.8mm (.032") | PZFR6H | ||
| Evinrude | 48 | 1987- | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 50 | 1978-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 55 | COMMERCIAL | 1982- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Evinrude | 55 | COMMERCIAL | 1984-1985 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Evinrude | 55 | COMMERCIAL | 1986- | 0 | BUHXW1 | |
| Evinrude | 55 | COMMERCIAL | 1987- | 0 | BUHW2 | |
| Evinrude | 55 | 1976-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 60 | 1980-1985 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 60 | 2005- | 0.8mm (.032") | PZFR6H | ||
| Evinrude | 65 | COMMERCIAL | 1984-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Evinrude | 65 | COMMERCIAL | 1987- | 0 | BUHW2 | |
| Evinrude | 70 | 1975-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 75 | HUSTLER | 1975- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Evinrude | 75 | 1976-1985 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 75 | 2001-2005 | 0.8mm (.032") | BKR5EK | ||
| Evinrude | 85 | 1975-1980 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 90 | 1981-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 90 | 2001-2005 | 0.8mm (.032") | BKR5EK | ||
| Evinrude | 90 | V4 FFI | 2000- | 0.8mm (.032") | PZFR6H | |
| Evinrude | 100 | COMMERCIAL | 1984- | 0 | L76V | |
| Evinrude | 100 | COMMERCIAL | 1985-1987 | 0 | BUHW2 | |
| Evinrude | 100 | 1979-1980 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 100 | 2004-2005 | 0.8mm (.032") | BKR5EK | ||
| Evinrude | 110 | 1986-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 115 | E-TECH | 2005- | 0.8mm (.032") | IZFR5J | |
| Evinrude | 115 | 1975-1984 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 115 | 1985- | 0 | L76V | ||
| Evinrude | 115 | 2004-2005 | 0.8mm (.032") | BKR5EK | ||
| Evinrude | 120 | 1985-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 125 | COMMERCIAL | 1990- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Evinrude | 140 | 140 S | 1977-1979 | 0 | BUHXW1 | |
| Evinrude | 140 | 1973-1984 | 0 | BUHXW1 | ||
| Evinrude | 140 | 1985-1992 | 1.0mm (.040") | BR9HS10 | ||
| Evinrude | 150 | 1978-1987 | 0 | BUHXW1 | ||
| Evinrude | 150 | 1988-1992 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 155 | COMMERCIAL | 1978-1986 | 0 | BUHXW1 | |
| Evinrude | 155 | COMMERCIAL | 1987- | 0 | BUHW2 | |
| Evinrude | 155 | COMMERCIAL | 1989-1992 | 0 | BUZ8H | |
| Evinrude | 175 | 1977-1987 | 0 | BUHXW1 | ||
| Evinrude | 175 | 1988-1992 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 175 | 2005- | 0.8mm (.032") | IZFR5J | ||
| Evinrude | 185 | COMMERCIAL | 1984-1985 | 0 | BUHXW1 | |
| Evinrude | 185 | COMMERCIAL | 1990-1992 | 1.0mm (.040") | BR9HS10 | |
| Evinrude | 200 | F MODELS | 2005- | 0.8mm (.032") | PZFR6H | |
| Evinrude | 200 | F MODELS | 2005- | 0.8mm (.032") | PZFR6H | |
| Evinrude | 200 | F MODELS | 2005- | 0.8mm (.032") | PZFR6H | |
| Evinrude | 200 | 1976-1983 | 0 | BUHXW1 | ||
| Evinrude | 200 | 1986-1992 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Evinrude | 225 | F MODELS | 2005- | 0.8mm (.032") | PZFR6H | |
| Evinrude | 225 | 1986- | 1 | B9HS10 | BR9HS10 | |
| Evinrude | 235 | 1978-1985 | 0 | BUHXW1 | ||
| Evinrude | 250 | F MODELS | 2005- | 0.8mm (.032") | PZFR6H | |
| Evinrude | 250 | 1991-1992 | 1 | BR9HS10 | ||
| Evinrude | 275 | 1985-1988 | 1 | BR9HS10 | ||
| Evinrude | 300 | 1986-1992 | 1 | B9HS10 | BR9HS10 |
Honda Outboard Motor Spark Plug Chart
| Make | Model | Type | Year | Gap | Standard | Resistor |
| Honda | 8 | BFP 8D1 8.0HP | 2001- | 0.9mm (.036") | CR5EH9 | |
| Honda | 9.9 | BFP9.9D1 9.9HP | 2001- | 0.9mm (.036") | CR5EH9 | |
| Honda | 20 | BF20 | 0.6mm (.024") | BM4A | BMR4A | |
| Honda | 20 | BF20D | 2003- | 0.9mm (.036") | CR5EH9 | |
| Honda | 25 | BF25D4 | 2004- | 0.7mm (.028") | DR7EA | |
| Honda | 30 | BF30 | 0.7mm (.028") | D8EA | DR8EA | |
| Honda | 30 | BF30D4 | 2004- | 0.7mm (.028") | DR7EA | |
| Honda | 30 | GB-30 | 0.6mm (.024") | B6HS | BR6HS | |
| Honda | 40 | GB-40 | 0.6mm (.024") | B6HS | BR6HS | |
| Honda | 45 | B45 | 0.6mm (.024") | DR6HS | ||
| Honda | 50 | BF50 | 0.7mm (.028") | DR7EA | ||
| Honda | 60 | BF60 | 2009- | 0.9mm (.036") | LMAR6C9 | |
| Honda | 75 | B75 K | 0.6mm (.024") | DR6HS | ||
| Honda | 75 | BF75 | 2003- | 0.7mm (.028") | DR7EA | |
| Honda | 75 | BF75 E | 0.6mm (.024") | DR6HS | ||
| Honda | 75 | BF75A | 0.7mm (.028") | DR7EA | ||
| Honda | 100 | BF100 E | 0.6mm (.024") | DR6HS | ||
| Honda | 115 | BF115 | 0.8mm (.032") | ZFR7F | ||
| Honda | 125 | AQUA TRAX R-12 | 2002-2006 | 0.9mm (.036") | IMR9D9H | |
| Honda | 200 | BF200A V6 | 2002- | 1.1mm (.044") | IZFR6K11 | ZFR6K11 |
| Honda | 225 | BF225A V6 | 2002- | 1.1mm (.044") | IZFR6K11 | ZFR6K11 |
| Make | Model | Type | Year | Gap | Standard | Resistor |
| Johnson | 1.5mm (.060") | 1986-1987 | 0.7mm (.028") | B6S | ||
| Johnson | 1.6 | 1.6 L 115-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 1.8 | 1.8 L 140-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 2 | 2R | 1971-1979 | 0.7mm (.028") | B6S | |
| Johnson | 2 | 1980-1985 | 0.7mm (.028") | B6S | ||
| Johnson | 2.5 | 1986- | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 2.6 | 2.6 L 190-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 2.7 | 2.7 L 225-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 3.5 | 2001-2002 | 0.7mm (.028") | BPR6HS | ||
| Johnson | 3.6 | 3.6 L 275-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 4 | DEL. | 1986-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 4 | R,RW | 1977-1980 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 4 | 1985-1987 | 0.6mm (.024") | B6HS | BR6HS | |
| Johnson | 4.5 | 1979-1980 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 6 | 1977-1979 | 0 | BUHW2 | ||
| Johnson | 6 | 1984-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 7.5 | 1980-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 8 | 1984-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 8 | 2002- | 0.7mm (.028") | DR5HS | ||
| Johnson | 9.9 | E,R,SEL | 1977-1979 | 0 | BUHW2 | |
| Johnson | 9.9 | 1980-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 10 | COMMERCIAL | 1981-1982 | 0 | BUHW2 | |
| Johnson | 10 | 2006-2006 | 0.8mm (.032") | BR7HS | ||
| Johnson | 14 | COMMERCIAL | 1981-1982 | 0 | BUHW2 | |
| Johnson | 15 | E,R | 1977-1979 | 0 | BUHW2 | |
| Johnson | 15 | 1980-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 15 | 2005- | 0.8mm (.032") | BKR6E | ||
| Johnson | 15 | 2006- | 0.8mm (.032") | BR7HS | ||
| Johnson | 20 | 1986-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 25 | COMMERCIAL | 1985-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 25 | E,R | 1977-1979 | 0 | BUHW2 | |
| Johnson | 25 | 1980-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 28 | 1985-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 30 | 1984-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 35 | E,R | 1977-1979 | 0 | BUHW2 | |
| Johnson | 35 | 1980-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 40 | 40E | 1985-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 40 | COMMERCIAL | 1981- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 40 | COMMERCIAL | 1982- | 0.7mm (.028") | B7HS | BR7HS |
| Johnson | 40 | COMMERCIAL | 1984-1986 | 0 | BUHW2 | |
| Johnson | 40 | 2002- | 0.7mm (.028") | DCPR7E | ||
| Johnson | 40 | 2005- | 0.7mm (.028") | DCPR6E | ||
| Johnson | 45 | COMMERCIAL | 1987- | 0 | BUHW2 | |
| Johnson | 50 | R | 1977-1979 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 50 | 2002- | 0.7mm (.028") | DCPR7E | ||
| Johnson | 50 | 1971-1980 | 0 | BUHW2 | ||
| Johnson | 50 | 1981-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 50 | 2005- | 0.7mm (.028") | DCPR6E | ||
| Johnson | 55 | COM | 1986-2005 | 0 | BUHXW1 | |
| Johnson | 55 | COMMERCIAL | 1980-1983 | 0 | L76V | |
| Johnson | 55 | COMMERCIAL | 1984-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 55 | E | 1976-1979 | 0 | L76V | |
| Johnson | 60 | 1980-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 60 | 2002-2005 | 0.8mm (.032") | BPR6ES | BP6ES | |
| Johnson | 65 | COMMERCIAL HC | 1984-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 65 | COMMERCIAL LC | 1986- | 0 | BUHXW1 | |
| Johnson | 70 | EL | 1976-1979 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 70 | 1980-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 70 | 2002-2005 | 0.8mm (.032") | BPR6ES | BP6ES | |
| Johnson | 75 | ER | 1976-1979 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 75 | 1980-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 85 | ML,ETLR,TXLR | 1977-1978 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 85 | ML,TL,TX | 1979-1980 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 90 | 1981-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 90 | 2003- | 0.8mm (.032") | BKR6E | ||
| Johnson | 90 | 2006- | 1.0mm (.040") | BPZ8HS10 | ||
| Johnson | 100 | COMMERCIAL | 1980- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 100 | COMMERCIAL | 1984-1987 | 0 | BUHW2 | |
| Johnson | 100 | ML,TLR,TXLR | 1979- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 110 | 1986-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 115 | 115ETL | 1974-1978 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 115 | 115ML | 1978-1979 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 115 | 115TL | 1979- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 115 | 115TXL | 1977-1979 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| Johnson | 115 | 1980-1985 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 115 | 2006- | 1.0mm (.040") | BPZ8HS10 | ||
| Johnson | 120 | 1985-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 140 | ML,TL,TXL | 1977-1979 | 0 | BUHXW1 | |
| Johnson | 140 | 1980-1984 | 0 | BUHXW1 | ||
| Johnson | 140 | 1985-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 140 | 2003-2005 | 0.8mm (.032") | BKR6E | ||
| Johnson | 150 | TL,TXL | 1978-1979 | 0 | BUHXW1 | |
| Johnson | 150 | 1980-1986 | 0 | BUHXW1 | ||
| Johnson | 150 | 1987- | 0 | BUHW2 | ||
| Johnson | 150 | 2003-2006 | 1.0mm (.040") | BPZ8HS10 | ||
| Johnson | 155 | COMMERCIAL | 1984-1986 | 0 | BUHXW1 | |
| Johnson | 175 | TL,TXL | 1977-1980 | 0 | BUHXW1 | |
| Johnson | 175 | 1977-1986 | 0 | BUHXW1 | ||
| Johnson | 175 | 1987- | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 185 | COMMERCIAL | 1984-1986 | 0 | BUHXW1 | |
| Johnson | 200 | TL,TXL | 1976-1980 | 0 | BUHXW1 | |
| Johnson | 200 | 1981-1986 | 0 | BUHXW1 | ||
| Johnson | 200 | 1987- | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 225 | 1986- | 0 | BUHXW1 | ||
| Johnson | 225 | 1987- | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 235 | TL,TXL | 1978-1980 | 0 | BUHXW1 | |
| Johnson | 235 | 1978-1985 | 0 | BUHXW1 | ||
| Johnson | 235 | 1981-1984 | 0 | BUHXW1 | ||
| Johnson | 250 | LV6 | 0 | BUZ8H | ||
| Johnson | 250 | 1993-1991 | 1.0mm (.040") | BPZ8HS10 | ||
| Johnson | 275 | 1985-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Johnson | 300 | 1983-1986 | 1.0mm (.040") | BPZ8HS10 | ||
| Johnson | 300 | 1994-1995 | 0.7mm (.028") | BPR6HS |
| Make | Model | Type Engine | Year | Gap | Standard | Resistor |
| Mariner | 2 | 2A 646 | 0.5mm (.020") | B5HS | BR5HS | |
| Mariner | 2 | 2B 6A1 | 0.5mm (.020") | B5HS | BR5HS | |
| Mariner | 2.5 | 1990- | 0.6mm (.024") | BP6HS | BPR6HS | |
| Mariner | 2.5 | 1990-2002 | 1.0mm (.040") | BPR6HS10 | ||
| Mariner | 3.3 | 642 | 1993- | 0.7mm (.028") | BPR6HS | |
| Mariner | 3.5 | 0.7mm (.028") | B7HS | BR7HS | ||
| Mariner | 3.5 | 0.7mm (.028") | B7HS | BR7HS | ||
| Mariner | 4 | 4A 6E0 | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 4 | 1990- | 1.0mm (.040") | BP7HS10 | BPR7HS11 | |
| Mariner | 4 | 4A6EO | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 4 | 2-Stroke | 1990-2002 | 1.0mm (.040") | BPR7HS10 | |
| Mariner | 4 | 4-Stroke | 1990-2002 | 0.7mm (.028") | DCPR6E | |
| Mariner | 4.4,5.5 | 1.0mm (.040") | BPR7HS10 | |||
| Mariner | 5 | 5B 661 | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 5 | 5C 6E3 | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 5 | 1990- | 1.0mm (.040") | BP7HS10 | BPR7HS11 | |
| Mariner | 5 | 2-Stroke | 1990-2002 | 1.0mm (.040") | BPR7HS10 | |
| Mariner | 5 | 4-Stroke | 1999-2002 | 0.7mm (.028") | DCPR6E | |
| Mariner | 6 | 2-Stroke | 1992-2002 | 1.0mm (.040") | BP8HN10 | |
| Mariner | 6 | 4-Stroke | 2000-2002 | 0.7mm (.028") | DCPR6E | |
| Mariner | 8 | 8A 655+647 | 0.6mm (.024") | B6HS | BR6HS | |
| Mariner | 8 | 8B 677 | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 8 | 8C 6G1 | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Mariner | 8 | 1993-2002 | 1.0mm (.040") | BP8HN10 | ||
| Mariner | 9 | 4-Stroke | 1999-2002 | 0.9mm (.036") | DPR6EA9 | |
| Mariner | 9.9 | C 682 | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 9.9 | 1.0mm (.040") | B7HS10 | BR7HS10 | ||
| Mariner | 10 | 1991- | 1.5mm (.060") | BP8HS15 | ||
| Mariner | 15 | A,C 684 + 651 | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 15 | C 684-CDI | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Mariner | 15 | MARATHON | 1997-2002 | 1.5mm (.060") | BP8HS15 | |
| Mariner | 15 | W 662 | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 15 | 4-Stroke | 1998-2002 | 0.9mm (.036") | DPR6EA9 | |
| Mariner | 20 | A 653 | 0.6mm (.024") | B6HS | BR6HS | |
| Mariner | 20 | C 6A9 | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 20 | 1985-2002 | 1.0mm (.040") | BP8HN10 | ||
| Mariner | 25 | C,A 695 + 648 | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 25 | MARATHON 4-Stroke | 1993-2002 | 1.0mm (.040") | BP8HN10 | |
| Mariner | 25 | W 6A4 | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 25 | 1998-2002 | 0.9mm (.036") | DPR6EA9 | ||
| Mariner | 28 | 0.7mm (.028") | B7HS | BR7HS | ||
| Mariner | 30 | MARATHON | 1995-2002 | 1.0mm (.040") | BP8HN10 | |
| Mariner | 30 | MARATHON,A,W 689+689B | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 30 | 4-Stroke | 1999-2002 | 0.9mm (.036") | DPR6EA9 | |
| Mariner | 30 | 2000- | 0.7mm (.028") | DCPR6E | ||
| Mariner | 40 | A 676A | 0.8mm (.032") | B8HS | BR8HS | |
| Mariner | 40 | C 6E9 | 0.8mm (.032") | B8HS | BR8HS | |
| Mariner | 40 | MARATHON | 1995-2002 | 1.0mm (.040") | BP8HN10 | |
| Mariner | 40 | W 676A,B | 0.8mm (.032") | B8HS | BR8HS | |
| Mariner | 40 | 2002- | 0.7mm (.028") | DCPR7E | ||
| Mariner | 40 | 2000- | 0.7mm (.028") | DCPR6E | ||
| Mariner | 40 | 2002- | 0.7mm (.028") | DCPR7E | ||
| Mariner | 45 | 0 | BUHW2 | |||
| Mariner | 48 | W 670 | 0.7mm (.028") | B7HS | BR7HS | |
| Mariner | 50 | 1990- | 0 | BUHW2 | ||
| Mariner | 50 | 1992- | 0 | BUZ8H | ||
| Mariner | 50 | 4-Stroke | 1995-2001 | 0.9mm (.036") | DPR6EA9 | |
| Mariner | 50 | 2000- | 0.7mm (.028") | DCPR6E | ||
| Mariner | 50 | 0 | L76V | |||
| Mariner | 50 | 0 | BUHW2 | |||
| Mariner | 55 | W55 6A3 | 0.8mm (.032") | B8HS | BR8HS | |
| Mariner | 55 | 1.0mm (.040") | B8HS10 | BR8HS10 | ||
| Mariner | 60 | EFI | 2002- | 0.7mm (.028") | DCPR7E | |
| Mariner | 60 | 1990- | 0 | BUHW2 | ||
| Mariner | 60 | 1992- | 0 | BUZ8H | ||
| Mariner | 60 | 2001- | 0.9mm (.036") | DPR6EA9 | ||
| Mariner | 60 | 0 | L76V | |||
| Mariner | 60 | 1.0mm (.040") | B8HS10 | BR8HS10 | ||
| Mariner | 60 | 1.0mm (.040") | BPZ8HN10 | |||
| Mariner | 60 | 1984-1990 | 0 | BUZHW | ||
| Mariner | 70 | 0 | L76V | |||
| Mariner | 75 | MARATHON | 1991-2002 | 0 | BUHW2 | |
| Mariner | 75 | 4-Stroke | 2000- | 1.1mm (.044") | LFR5A11 | |
| Mariner | 80 | 1995-2001 | 1.0mm (.040") | BP8HN10 | ||
| Mariner | 80 | 0 | BUHW2 | |||
| Mariner | 85 | 0 | BUHW2 | |||
| Mariner | 90 | 2000- | 1.1mm (.044") | LFR5A11 | ZFR5F11 | |
| Mariner | 90 | 0 | BUHW2 | |||
| Mariner | 90 | 0 | L76V | |||
| Mariner | 100 | 1988 | 0 | L76V | ||
| Mariner | 115 | OPTIMAX | 2000-2002 | 1.1mm (.044") | PZFR5F11 | ZFR5F11 |
| Mariner | 115 | 2-Stroke | 1989-2002 | 1.0mm (.040") | BP8HN10 | |
| Mariner | 115 | 0 | L76V | |||
| Mariner | 125 | 1.0mm (.040") | BPZ8HN10 | |||
| Mariner | 135 | MARATHON | 0 | BU8H | ||
| Mariner | 135 | OPTIMAX | 1998-2002 | 1.1mm (.044") | PZFR5F11 | ZFR5F11 |
| Mariner | 140 | 0 | BUZHW | |||
| Mariner | 140 | 0 | L76V | |||
| Mariner | 150 | MAGNUM | 2000- | 1.0mm (.040") | BPR7HS10 | |
| Mariner | 150 | OPTIMAX | 1997-2002 | 1.1mm (.044") | PZFR5F11 | ZFR5F11 |
| Mariner | 150 | V150 A905890 V6 | 0 | L76V | ||
| Mariner | 150 | V150 A905891 V6 | 0 | BU8H | ||
| Mariner | 150 | V6 EFI | 2000- | 1.0mm (.040") | BPZ8HS10 | |
| Mariner | 175 | EFI | 2000- | 1.0mm (.040") | BPZ8HS10 | |
| Mariner | 175 | MAGNUM | 2000- | 1.0mm (.040") | BPR7HS10 | |
| Mariner | 175 | V175 A918688 V6 | 0 | L76V | ||
| Mariner | 175 | V175 A918689 V6 | 0 | BU8H | ||
| Mariner | 200 | OPTIMAX | 1997-2002 | 1.1mm (.044") | PZFR5F11 | ZFR5F11 |
| Mariner | 200 | V200 A914497 V6 | 0 | L76V | ||
| Mariner | 200 | V200 A914498 V6 | 0 | BU8H | ||
| Mariner | 200 | 1997-1999 | 0 | BU8H | ||
| Mariner | 200 | 2000- | 1.0mm (.040") | BPR7HS10 | ||
| Mariner | 220 | V220 | 0 | BU8H | ||
| Mariner | 225 | OPTIMAX | 1.1mm (.044") | PZFR5F11 | ZFR5F11 | |
| Mariner | 225 | OPTIMAX | 1996-2001 | 1.0mm (.040") | BPZ8HN10 | |
| Mariner | 225 | 0 | BU8H | |||
| Mariner | 250 | MAGNUM | 1991-1994 | 0.8mm (.032") | BR8HS | |
| Mariner | 250 | 0 | BU8H | |||
| Mariner | 275 | 0 | BU8H |
| Make | Model | Type Engine | Year | Gap | Standard | Resistor |
| Mercury | 2.2 | 2.2,2.5,3,3.3 HP | 1.0mm (.040") | BPR6HS10 | ||
| Mercury | 2.2 | 1984-1989 | 0.6mm (.024") | BP6HS | BPR6HS | |
| Mercury | 2.5 | 0.7mm (.028") | BPR6HS | |||
| Mercury | 3.4 | L | 1984-1986 | 0 | L76V | |
| Mercury | 3.4 | L | 1987-1988 | 0 | BU8H | |
| Mercury | 3.5 | 1983-1985 | 0.7mm (.028") | BP7HS | ||
| Mercury | 3.6 | 1980-1981 | 0.7mm (.028") | BP7HS | ||
| Mercury | 3.6 | 1982- | 0.7mm (.028") | BP7HS | ||
| Mercury | 3.9 | 1967-1968 | 0.5mm (.020") | B5HS | BR5HS | |
| Mercury | 4 | L4SC 1.73L | 2007- | 0.8mm (.032") | ILFR6GE | |
| Mercury | 4 | 1976-1979 | 0.6mm (.024") | B6HS | BR6HS | |
| Mercury | 4 | 1980-1989 | 0.7mm (.028") | BP7HS | ||
| Mercury | 4 | 1986-1987 | 0 | BUHW2 | ||
| Mercury | 4.5 | 1975-1985 | 0 | BUHW2 | ||
| Mercury | 5 | 1988-1989 | 1.0mm (.040") | BP7HS10 | BPR7HS11 | |
| Mercury | 6 | 1986- | 1.0mm (.040") | BP7HS10 | BPR7HS11 | |
| Mercury | 6 | 1987-1989 | 1.0mm (.040") | BP8HS10 | ||
| Mercury | 6 | 1993-1994 | 1.0mm (.040") | BPZ8HN10 | ||
| Mercury | 6 | 2-Stroke | 2001-2006 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 7.5 | 1975-1978 | 0 | BUHW2 | ||
| Mercury | 7.5 | 1979-1985 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Mercury | 8 | 1986- | 1.0mm (.040") | BP7HS10 | BPR7HS11 | |
| Mercury | 8 | 1987-1989 | 1.0mm (.040") | BP8HS10 | ||
| Mercury | 8 | 1993-1994 | 1.0mm (.040") | BPZ8HN10 | ||
| Mercury | 8 | 2-Stroke | 2001-2006 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 8 | 4-Stroke | 2006-2006 | 0.7mm (.028") | DCPR6E | |
| Mercury | 9.8 | 1975-1978 | 0 | BUHW2 | ||
| Mercury | 9.8 | 1979-1985 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Mercury | 9.9 | 1986- | 1.0mm (.040") | BP7HS10 | BPR7HS11 | |
| Mercury | 9.9 | 1987-1989 | 1.0mm (.040") | BP8HS10 | ||
| Mercury | 9.9 | 1993-1994 | 1.0mm (.040") | BPZ8HN10 | ||
| Mercury | 9.9 | 2-Stroke | 2001-2006 | 1.0mm (.040") | BPZ8HS10 | |
| Mercury | 9.9 | 4-Stroke | 2006- | 0.7mm (.028") | DCPR6E | |
| Mercury | 10 | SEAPRO | 1.5mm (.060") | BP8HS15 | ||
| Mercury | 15 | 2-Stroke | 2001-2006 | 1.0mm (.040") | BPZ8HS10 | |
| Mercury | 15 | 1.0mm (.040") | BP8HS10 | |||
| Mercury | 18 | X | 1984-1985 | 0 | L76V | |
| Mercury | 18 | 1980-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| Mercury | 20 | 20 | 1986-1989 | 0 | L76V | |
| Mercury | 20 | 20200 | 1970-1980 | 0 | BUHW2 | |
| Mercury | 20 | 1992-1994 | 1.0mm (.040") | BPZ8HN10 | ||
| Mercury | 20 | 2-Stroke | 2001-2006 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 25 | 250 | 1980-1983 | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Mercury | 25 | 25XD | 1984-1989 | 0 | L76V | |
| Mercury | 25 | SEA-PRO | 1993-1994 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 25 | 2-Stroke | 2001-2006 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 25 | 4-Stroke | 2006- | 0.7mm (.028") | DCPR6E | |
| Mercury | 30 | 303 4-Stroke | 2006- | 0.7mm (.028") | DCPR7E | |
| Mercury | 30 | 1.0mm (.040") | BPZ8HN10 | |||
| Mercury | 35 | 350 | 1984-1989 | 0 | L76V | |
| Mercury | 40 | 40 | 1979-1983 | 0 | L76V | |
| Mercury | 40 | 403 4-Stroke | 2006- | 0.7mm (.028") | DCPR7E | |
| Mercury | 40 | BIG FOOT 4-Stroke | 2001-2006 | 0.9mm (.036") | DPR6EA9 | |
| Mercury | 40 | SEA PRO 2-Stroke | 2001-2006 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 45 | 45 | 1986-1989 | 0 | BUHW2 | |
| Mercury | 50 | 50 | 1986-1988 | 0 | L76V | |
| Mercury | 50 | 503 2-Stroke | 2001-2006 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 50 | 504 4-Stroke | 2006- | 0.7mm (.028") | DCPR7E | |
| Mercury | 50 | 50500 | 1976-1985 | 0 | BUHW2 | |
| Mercury | 50 | 1993-1994 | 1.0mm (.040") | BPZ8HN10 | ||
| Mercury | 55 | SEA-PRO | 1993-1994 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 60 | 600 | 1984-1989 | 0 | L76V | |
| Mercury | 60 | 603 2-Stroke | 2001-2006 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 60 | 604 4-Stroke | 2006- | 0.7mm (.028") | DCPR7E | |
| Mercury | 70 | 70 | 1987-1989 | 0 | BUHW2 | |
| Mercury | 70 | 700 | 1979-1983 | 0 | L76V | |
| Mercury | 75 | 750 | 1984-1986 | 0 | BUHW2 | |
| Mercury | 75 | 753 2-Stroke | 2001-2006 | 0 | BUZHW2 | |
| Mercury | 75 | 754 4-Stroke | 2000-2006 | 1.1mm (.044") | LFR5A11 | |
| Mercury | 75 | OPTI MAX | 2006- | 0.8mm (.032") | IZFR5J | |
| Mercury | 80 | 80800 | 78-83, 86-89 | 0 | BUHW2 | |
| Mercury | 85 | 850 | 1977- | 0 | BUHW2 | |
| Mercury | 90 | 90 | 1987-1989 | 0 | BUHW2 | |
| Mercury | 90 | 90 4-Stroke | 2000-2006 | 1.1mm (.044") | LFR5A11 | |
| Mercury | 90 | 90 OPTI MAX | 2006- | 0.8mm (.032") | IZFR5J | |
| Mercury | 90 | 90900 | 1978-1986 | 0 | L76V | |
| Mercury | 100 | 100 | 1988-1989 | 0 | L76V | |
| Mercury | 100 | 1991-1994 | 1.0mm (.040") | BPZ8HN10 | ||
| Mercury | 115 | 115, 1150 | 1970-1988 | 0 | L76V | |
| Mercury | 115 | OPTI MAX | 2006- | 0.8mm (.032") | IZFR5J | |
| Mercury | 115 | 1991-1994 | 1.0mm (.040") | BPZ8HN10 | ||
| Mercury | 115 | 2-Stroke 1154 | 2001-2006 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 115 | 4-Stroke MFI4 | 2001-2006 | 1.1mm (.044") | LFR5A11 | |
| Mercury | 125 | 1994 | 1.0mm (.040") | BPZ8HN10 | ||
| Mercury | 125 | 2-Stroke 1254 | 2001-2006 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 135 | OPTI MAX 2-Stroke DFI6 | 2003-2006 | 0.8mm (.032") | IZFR5G | |
| Mercury | 135 | V-135 | 1969-1989 | 0 | BU8H | |
| Mercury | 135 | 4-Stroke EFI6 | 2006- | 0.7mm (.028") | ILFR6G | |
| Mercury | 140 | 140, 1400 | 1978-1980 | 0 | L76V | |
| Mercury | 150 | 150, 1500 | 1973-1984 | 0 | L76V | |
| Mercury | 150 | XR-4,V-150 | 1985-1989 | 0 | BU8H | |
| Mercury | 150 | 2-Stroke EFI6 | 2000-2006 | 1.0mm (.040") | BPZ8HS10 | |
| Mercury | 150 | 2000-2006 | 1.0mm (.040") | BPZ8HS10 | ||
| Mercury | 150 | 4STROKE EFI6 | 2006- | 0.7mm (.028") | ILFR6G | |
| Mercury | 150 | OPTI MAX | 1.1mm (.044") | PZFR5F11 | ZFR5F11 | |
| Mercury | 175 | 1751750 | 1976-1981 | 0 | L76V | |
| Mercury | 175 | OPTI MAX 2-Stroke | 2003-2006 | 0.8mm (.032") | IZFR5G | |
| Mercury | 175 | SUPERCHARGED 4-Stroke EFI6 | 2006- | 0.7mm (.028") | ILFR6G | |
| Mercury | 175 | V-175 | 1986-1989 | 0 | BU8H | |
| Mercury | 200 | 2002000 | 1978-1985 | 0 | L76V | |
| Mercury | 200 | OPTI MAX 2-Stroke MAX 6 | 2003-2006 | 0.8mm (.032") | IZFR5G | |
| Mercury | 200 | V-200 | 1986-1989 | 0 | BU8H | |
| Mercury | 200 | VERADO 200-275 4-Stroke | 0.7mm (.028") | ILFR6G | ||
| Mercury | 200 | 2000- | 1.0mm (.040") | BPZ8HS10 | ||
| Mercury | 200 | 2-Stroke MF16 | 2000-2006 | 1.0mm (.040") | BPZ8HS10 | |
| Mercury | 200 | 2-Stroke EFI6 | 2006- | 0.8mm (.032") | BR8HS | |
| Mercury | 200 | 4-Stroke EFI6 | 2006- | 0.7mm (.028") | ILFR6G | |
| Mercury | 200 | OPTI MAX | 1.1mm (.044") | PZFR5F11 | ZFR5F11 | |
| Mercury | 220 | V-220 | 1987-1988 | 0 | BU8H | |
| Mercury | 225 | 225 | 1980-1981 | 0 | L76V | |
| Mercury | 225 | 3.0L | 1994-1997 | 1.0mm (.040") | BPZ8HN10 | |
| Mercury | 225 | OPTI MAX 2-Stroke | 2006- | 0.8mm (.032") | IZFR5G | |
| Mercury | 225 | 1994 | 1.0mm (.040") | BPZ8HN10 | ||
| Mercury | 225 | 2-Stroke | 1995-2006 | 0.8mm (.032") | BR8HS | |
| Mercury | 225 | 4-Stroke | 2006- | 1.1mm (.044") | LFR5A11 | |
| Mercury | 250 | OPTI MAX | 2003-2006 | 0.7mm (.028") | IZFR6J | |
| Mercury | 250 | SUPERCHARGED | 2006- | 0.7mm (.028") | ILFR6G | |
| Mercury | 250 | 0 | BU8H | |||
| Mercury | 275 | 2006- | 0.7mm (.028") | ILFR6G | ||
| Mercury | 300 | 300 | 1980-1983 | 0 | L76V | |
| Mercury | 300 | OPTIMAX 300XS 3.16L | 2007- | 0.8mm (.032") | IZFR7M |
| Make | Model | Type Engine | Year | Gap | Standard | Resistor |
| Suzuki | 2 | DT2 | 0.5mm (.020") | B5HS | BR5HS | |
| Suzuki | 3.5 | DT3.5 | 0.6mm (.024") | BP6HS | BPR6HS | |
| Suzuki | 4 | DT4 | 1985- | 0.6mm (.024") | B6HS | BR6HS |
| Suzuki | 4 | DT4 | 1986- | 0.6mm (.024") | BP6HS | BPR6HS |
| Suzuki | 4 | DF4 | 2003-2004 | 0.8mm (.032") | BPR6ES | BP6ES |
| Suzuki | 5 | DT5 | 0.6mm (.024") | BP6HS | BPR6HS | |
| Suzuki | 5 | DT5W | 0.6mm (.024") | BP6HS | BPR6HS | |
| Suzuki | 6 | DF6 | 2003-2004 | 0.8mm (.032") | BPR6ES | BP6ES |
| Suzuki | 6 | DT6 | 1985- | 0.6mm (.024") | B6HS | BR6HS |
| Suzuki | 6 | DT6 | 1986- | 0.6mm (.024") | BP6HS | BPR6HS |
| Suzuki | 6 | DF6 | 2003-2004 | 0.8mm (.032") | BPR6ES | BP6ES |
| Suzuki | 6 | DT6 | 1993-2002 | 0.8mm (.032") | BR6HS | |
| Suzuki | 7 | DT7 | 1985- | 0.6mm (.024") | B6HS | BR6HS |
| Suzuki | 8 | DT8,C | 0.6mm (.024") | BP6HS | BPR6HS | |
| Suzuki | 9.9 | DF9.9 4-Stroke | 1996-2004 | 0.7mm (.028") | DCPR6E | |
| Suzuki | 9.9 | DT9.9 | 1979-1983 | 0.6mm (.024") | B6HS | BR6HS |
| Suzuki | 9.9 | DT9.9C | 1986- | 0.7mm (.028") | B7HS | BR7HS |
| Suzuki | 15 | DF15 4-Stroke | 1996-2004 | 0.7mm (.028") | DCPR6E | |
| Suzuki | 15 | DF152 4-Stroke | 1996-2004 | 0.7mm (.028") | DCPR6E | |
| Suzuki | 15 | DT15 | 1983- | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Suzuki | 15 | DT15C | 1984- | 0.7mm (.028") | B7HS | BR7HS |
| Suzuki | 15 | DT15E | 1983- | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Suzuki | 15 | DT15E | 1984- | 0.7mm (.028") | B7HS | BR7HS |
| Suzuki | 15 | DT15K | 1986- | 0.6mm (.024") | B6HS | BR6HS |
| Suzuki | 16 | DT16 | 0.7mm (.028") | B7HS | BR7HS | |
| Suzuki | 16 | DT16P | 0.7mm (.028") | B7HS | BR7HS | |
| Suzuki | 20 | DT20 | 1985- | 0.7mm (.028") | B7HS | BR7HS |
| Suzuki | 20 | DT20 | 1986- | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Suzuki | 20 | DT20P | 1985- | 0.7mm (.028") | B7HS | BR7HS |
| Suzuki | 25 | DF253 4-Stroke | 2000-2004 | 0.7mm (.028") | DCPR6E | |
| Suzuki | 25 | DT25 | 0.7mm (.028") | B7HS | BR7HS | |
| Suzuki | 25 | DT25E | 1986- | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Suzuki | 28 | DT28 | 0.7mm (.028") | B7HS | BR7HS | |
| Suzuki | 30 | DF303 4-Stroke | 2000-2004 | 0.7mm (.028") | DCPR6E | |
| Suzuki | 30 | DT30 | 1983-1985 | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Suzuki | 30 | DT30C | 1986- | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Suzuki | 40 | DF40 4-Stroke | 1999-2004 | 0.7mm (.028") | DCPR6E | |
| Suzuki | 40 | DT40,C | 0.8mm (.032") | B8HS | BR8HS | |
| Suzuki | 50 | DF50 | 1999-2004 | 0.7mm (.028") | DCPR6E | |
| Suzuki | 50 | DF50 4-Stroke | 0.7mm (.028") | DCPR6E | ||
| Suzuki | 50 | DT50 | 0.8mm (.032") | B8HS | BR8HS | |
| Suzuki | 55 | DT55,C | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Suzuki | 60 | DF60 4-Stroke | 1998-2004 | 0.8mm (.032") | BPR6ES | BP6ES |
| Suzuki | 60 | DT60 | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Suzuki | 65 | DT65,C | 0.8mm (.032") | B8HS | BR8HS | |
| Suzuki | 70 | DF70 4-Stroke | 1998-2004 | 0.8mm (.032") | BPR6ES | BP6ES |
| Suzuki | 75 | DT75 | 1985- | 0.8mm (.032") | B8HS | BR8HS |
| Suzuki | 75 | DT75C | 1985- | 0.8mm (.032") | B8HS | BR8HS |
| Suzuki | 75 | DT75C | 1986- | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Suzuki | 85 | DT85,C | 0.8mm (.032") | B8HS | BR8HS | |
| Suzuki | 90 | DF90 4-Stroke | 2001-2004 | 0.8mm (.032") | BKR6E | |
| Suzuki | 100 | DT100C | 1.0mm (.040") | BR8HCS10 | ||
| Suzuki | 115 | DF115 4-Stroke | 2001-2005 | 0.8mm (.032") | BKR6E | |
| Suzuki | 115 | DT115/C | 0.8mm (.032") | B8HS | BR8HS | |
| Suzuki | 140 | DF140 4-Stroke | 2002-2004 | 0.8mm (.032") | BKR6E | |
| Suzuki | 140 | DT140/C | 0.8mm (.032") | B8HS | BR8HS | |
| Suzuki | 150 | DT150 | 1987-2003 | 1.0mm (.040") | BR8HS10 | |
| Suzuki | 150 | DT150 | 0.8mm (.032") | B8HS | BR8HS | |
| Suzuki | 150 | DT150C | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Suzuki | 200 | DT200TC | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Suzuki | 200 | DT200,C,S | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Suzuki | 225 | DF225 V6 | 2004-2004 | 0.8mm (.032") | BKR6E | |
| Suzuki | 225 | DT225 EFI | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Suzuki | 225 | DT225 V6 | 1987-2003 | 1.0mm (.040") | BR8HS10 | |
| Suzuki | 250 | DF250 V6 | 2004- | 0.8mm (.032") | BKR6E |
| Make | Model | Type Engine | Year | Gap | Standard | Resistor |
| Tohatsu | 2.5 | M2.5A | 0.6mm (.024") | BP6HS | BPR6HS | |
| Tohatsu | 3.5 | M3.5A | 1985- | 0.7mm (.028") | B7HS | BR7HS |
| Tohatsu | 3.5 | M3.5A | 1986- | 0.6mm (.024") | BP6HS | BPR6HS |
| Tohatsu | 5 | M5A2 S | 0.7mm (.028") | B7HS | BR7HS | |
| Tohatsu | 5 | M5B S | 0.7mm (.028") | BP7HS | ||
| Tohatsu | 8 | M8A | 0.7mm (.028") | B7HS | BR7HS | |
| Tohatsu | 9.8 | M9.8A | 0.7mm (.028") | B7HS | BR7HS | |
| Tohatsu | 9.9 | M9.9A | 0.7mm (.028") | B7HS | BR7HS | |
| Tohatsu | 9.9 | M9.9B | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Tohatsu | 12 | M12A | 0.7mm (.028") | B7HS | BR7HS | |
| Tohatsu | 12 | M12B | 0.7mm (.028") | B7HS | BR7HS | |
| Tohatsu | 12 | M12C | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Tohatsu | 15 | M15A | 0.7mm (.028") | B7HS | BR7HS | |
| Tohatsu | 15 | M15B | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Tohatsu | 16 | M16A2 | 0.7mm (.028") | B7HS | BR7HS | |
| Tohatsu | 18 | M18A | 0.7mm (.028") | B7HS | BR7HS | |
| Tohatsu | 18 | M18C | 1982-1986 | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Tohatsu | 20 | M20A2 | 0.7mm (.028") | B7HS | BR7HS | |
| Tohatsu | 25 | M25A2 | 0.7mm (.028") | B7HS | BR7HS | |
| Tohatsu | 25 | M25B | 1984- | 0.7mm (.028") | B7HS | BR7HS |
| Tohatsu | 25 | M25B | 1985- | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Tohatsu | 25 | M25C | 1984-1986 | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Tohatsu | 25 | M25C2 | 1986-2006 | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Tohatsu | 25 | MSF25A 4-Stroke | 2004-2006 | 0.7mm (.028") | DCPR6E | |
| Tohatsu | 30 | M30A | 1985- | 0.7mm (.028") | B7HS | BR7HS |
| Tohatsu | 30 | M30A | 1986- | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Tohatsu | 30 | M30A2 | 1984- | 0.7mm (.028") | B7HS | BR7HS |
| Tohatsu | 30 | M30A2 | 1985- | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Tohatsu | 30 | M30A3 | 2004-2006 | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Tohatsu | 30 | MSF30A 4-Stroke | 2004-2006 | 0.7mm (.028") | DCPR6E | |
| Tohatsu | 35 | M35B | 0.7mm (.028") | BP7HS | ||
| Tohatsu | 40 | M40C | 1983-2006 | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Tohatsu | 40 | M40C | 1984- | 0.7mm (.028") | BP7HS | |
| Tohatsu | 40 | M40C | 1985- | 1.0mm (.040") | B7HS10 | BR7HS10 |
| Tohatsu | 40 | MD40ATLDI | 2004-2006 | 1.1mm (.044") | ZFR6F11 | |
| Tohatsu | 40 | MD40BTLDI | 2004-2006 | 0.8mm (.032") | PZFR6H | |
| Tohatsu | 50 | M50C | 2004-2006 | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Tohatsu | 50 | MD50ATLDI | 2004-2006 | 1.1mm (.044") | ZFR6F11 | |
| Tohatsu | 50 | MD50BTLDI | 2004-2006 | 0.8mm (.032") | PZFR6H | |
| Tohatsu | 55 | M55A | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Tohatsu | 55 | M55B | 2004-2006 | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Tohatsu | 55 | M55B | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Tohatsu | 60 | M60A | 2004-2006 | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Tohatsu | 60 | M60B | 1992-2006 | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Tohatsu | 70 | M70A | 2004-2006 | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Tohatsu | 70 | M70A | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Tohatsu | 70 | MD70ATLDI | 2004-2006 | 1.1mm (.044") | ZFR6F11 | |
| Tohatsu | 70 | MD70BTLDI | 2004-2006 | 0.8mm (.032") | PZFR6H | |
| Tohatsu | 90 | M90A | 1997-2006 | 1.0mm (.040") | BR8HS10 | |
| Tohatsu | 90 | MD90ATLDI | 2004-2006 | 1.1mm (.044") | ZFR6F11 | |
| Tohatsu | 90 | MD90BTLDI | 2004-2006 | 0.8mm (.032") | PZFR6H | |
| Tohatsu | 115 | M115A | 2004-2006 | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Tohatsu | 120 | M120A | 2004-2006 | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Tohatsu | 140 | M140A | 1997-2006 | 1.0mm (.040") | BR8HS10 |
| Make | Model | Type Engine | Year | Gap | Standard | Resistor |
| Yamaha | 2 | 2CMHS 2-Stroke | 1984-2002 | 0.8mm (.032") | B5HS | BR5HS |
| Yamaha | 2 | A | 0.6mm (.024") | B6HS | BR6HS | |
| Yamaha | 2 | B 2-Stroke | 1984- | 0.5mm (.020") | B5HS | BR5HS |
| Yamaha | 2 | B | 1985- | 0.7mm (.028") | B7HS | BR7HS |
| Yamaha | 2.5 | 4-Stroke | 2003-2005 | 0.7mm (.028") | BR6HS | |
| Yamaha | 3 | 3AMHS 2-Stroke | 1990- | 0.7mm (.028") | BR6HS | |
| Yamaha | 3 | 1988-2002 | 0.8mm (.032") | BR6HS | ||
| Yamaha | 3.5 | A | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 3.5 | AC | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 3.5 | AL | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 4 | A | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 4 | ACS | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 4 | AS | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 4 | F8CMHL 4-Stroke | 1999-2005 | 0.7mm (.028") | BR6HS | |
| Yamaha | 4 | 4-Stroke | 1999-2005 | 0.7mm (.028") | BR6HS | |
| Yamaha | 5 | 5CMHC 2-Stroke | 1985-2002 | 0.8mm (.032") | BR7HS | |
| Yamaha | 5 | 5CMHL 2-Stroke | 1984- | 0.7mm (.028") | B7HS | BR7HS |
| Yamaha | 5 | DPE | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Yamaha | 6 | A | 0.6mm (.024") | B6HS | BR6HS | |
| Yamaha | 6 | B | 0.5mm (.020") | B5HS | BR5HS | |
| Yamaha | 6 | 4-Stroke | 2001-2005 | 0.8mm (.032") | BR6HS | |
| Yamaha | 7 | A | 0.6mm (.024") | B6HS | BR6HS | |
| Yamaha | 8 | 8CMHL 2-Stroke | 2006-2010 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 8 | 8CMHS 2-Stroke | 2006-2010 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 8 | A | 0.6mm (.024") | B6HS | BR6HS | |
| Yamaha | 8 | B | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 8 | BK | 0.6mm (.024") | B6HS | BR6HS | |
| Yamaha | 8 | E8DMHL 2-Stroke | 1986-2005 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 8 | YEMS V8MTR 350 CUBIC INCH | 0.8mm (.032") | BR6FS | ||
| Yamaha | 8 | 4-Stroke | 2001-2005 | 0.8mm (.032") | BR6HS | |
| Yamaha | 9 | A | 0.6mm (.024") | B6HS | BR6HS | |
| Yamaha | 9 | F9.9 4-Stroke | 2005- | 0.9mm (.036") | DPR6EA9 | |
| Yamaha | 9.5 | A | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 9.9 | CPE CE C BE B | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 9.9 | D | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Yamaha | 9.9 | DE | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Yamaha | 9.9 | DPE | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Yamaha | 9.9 | DS | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Yamaha | 9.9 | F9.9 BM 4-Stroke | 1985-2004 | 0.7mm (.028") | C6HSA | CR6HSA |
| Yamaha | 9.9 | F9.9FMHL 4-Stroke | 1985-2004 | 0.7mm (.028") | CR6HSA | |
| Yamaha | 9.9 | F9.9FMHS 4-Stroke | 1985-2004 | 0.7mm (.028") | CR6HSA | |
| Yamaha | 9.9 | FT9.9GEL | 0.7mm (.028") | CR6HSA | ||
| Yamaha | 12 | A 2-Stroke | 2006-2010 | 0.7mm (.028") | B7HS | BR7HS |
| Yamaha | 15 | 15FMHL 2-Stroke | 2006-2010 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 15 | 15FMHS | 1.0mm (.040") | BR7HS10 | ||
| Yamaha | 15 | A,B BE C CE CPE | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 15 | E15 AK 2-Stroke | 2006-2010 | 0.6mm (.024") | B6HS | BR6HS |
| Yamaha | 15 | E15DMHL 4-Stroke | 1998- | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 15 | F15CMHL 4-Stroke | 1998- | 0.9mm (.036") | DPR6EA9 | |
| Yamaha | 15 | F15CMHS 4-Stroke | 1998-2004 2 | 0.9mm (.036") | DPR6EA9 | |
| Yamaha | 15 | 0.9mm (.036") | DPR6EA9 | |||
| Yamaha | 20 | A,B,AE | 0.6mm (.024") | B6HS | BR6HS | |
| Yamaha | 20 | BE | 0.6mm (.024") | B6HS | BR6HS | |
| Yamaha | 20 | BMK | 0.6mm (.024") | B6HS | BR6HS | |
| Yamaha | 20 | C,CE | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 20 | F20BMHS 4-Stroke | 1999- | 0.9mm (.036") | DPR6EA9 | |
| Yamaha | 25 | 25BMHL 2-Stroke | 2006-2010 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 25 | 25BMHS 2-Stroke | 2006-2010 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 25 | 25N | 1990- | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 25 | AE A AF B BE C | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 25 | CE D DE | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 25 | CMK DMS DM | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 25 | E25BMHL 2-Stroke | 1984-2005 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 25 | F25DEL 4-Stroke | 1998-2005 | 0.9mm (.036") | DPR6EA9 | |
| Yamaha | 25 | F25DMHL 4-Stroke | 1998-2005 | 0.9mm (.036") | DPR6EA9 | |
| Yamaha | 25 | F25DMHS 4-Stroke | 1998-2005 | 0.9mm (.036") | DPR6EA9 | |
| Yamaha | 28 | A | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 28 | AE | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 30 | 30HMHL 2-Stroke | 1987-2002 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 30 | 30HMHS 2-Stroke | 1987-2002 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 30 | 30HWL 2-Stroke | 1987-2002 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 30 | A | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 30 | AE | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 30 | AM | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 30 | B | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 30 | BM | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 30 | D | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Yamaha | 30 | DMS | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Yamaha | 30 | F30 4-Stroke | 2001-2005 | 0.9mm (.036") | DPR6EA9 | |
| Yamaha | 40 | 40XMHL 2-Stroke | 1987- | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 40 | 40XMHS 2-Stroke | 2006-2010 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 40 | 40XWL 2-Stroke | 1992- | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 40 | 40XWTL 2-Stroke | 1989- | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 40 | AE | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 40 | AM | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 40 | AR | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 40 | BE | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 40 | BM | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 40 | BR | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 40 | C | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 40 | CE | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 40 | CM | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 40 | D | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 40 | DM DE DR F FE | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 40 | E40XMHL 2-Stroke | 1989-1997 | 1.0mm (.040") | BR7HS10 | |
| Yamaha | 40 | F40C | 0.9mm (.036") | DPR5EA9 | ||
| Yamaha | 40 | F40FEDL 4-Stroke | 2000-2005 | 0.9mm (.036") | DPR6EA9 | |
| Yamaha | 40 | F40FEHDL 4-Stroke | 2000- | 0.9mm (.036") | DPR6EA9 | |
| Yamaha | 40 | F40FETL 4-Stroke | 2000-2005 | 0.9mm (.036") | DPR6EA9 | |
| Yamaha | 40 | H | 1.0mm (.040") | B7HS10 | BR7HS10 | |
| Yamaha | 40 | HMOS 2-Stroke | 1984-2005 | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Yamaha | 40 | 1.0mm (.040") | B7HS10 | BR7HS10 | ||
| Yamaha | 48 | A | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 48 | B | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 50 | 50HETOL 2-Stroke | 2006-2010 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 50 | 50HMHOS 2-Stroke | 1984-2005 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 50 | C | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 50 | CE | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 50 | D | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 50 | DROS | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 50 | F50A,B | 0.9mm (.036") | DPR6EA9 | ||
| Yamaha | 50 | F50GETL 4-Stroke | 2005- | 0.9mm (.036") | DPR6EB9 | |
| Yamaha | 50 | 2005- | 0.9mm (.036") | DPR6EB9 | ||
| Yamaha | 55 | 55BEDL 2-Stroke | 1989-1995 | 1.0mm (.040") | BR8HS10 | BR8HS10 |
| Yamaha | 55 | AE | 1979- | 1.0mm (.040") | B8HS10 | BR8HS |
| Yamaha | 55 | AEM AE AM AW | 0.8mm (.032") | B8HS | BR8HS10 | |
| Yamaha | 55 | BE | 1.0mm (.040") | B8HS10 | BR8HS | |
| Yamaha | 55 | BM BW | 0.8mm (.032") | B8HS | ||
| Yamaha | 55 | E55CMHL 2-Stroke | 1989-1995 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 60 | 60FETOL 2-Stroke | 2006-2010 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 60 | AE | 1978- | 0.8mm (.032") | B8HS | BR8HS |
| Yamaha | 60 | AE | 1979- | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Yamaha | 60 | B | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 60 | BE | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 60 | CE | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 60 | CET | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 60 | DE | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 60 | E60HMHDL 2-Stroke | 2001-2005 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 60 | F | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 60 | F60 EFI EFI | 2005- | 0.9mm (.036") | DPR6EB9 | |
| Yamaha | 60 | F60A 4 STR | 2002- | 0.9mm (.036") | DPR5EA9 | |
| Yamaha | 60 | FEOS | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 60 | FT60B 4 STR | 0.9mm (.036") | DPR5EA9 | ||
| Yamaha | 60 | FT60DET | 2006- | 0.9mm (.036") | DPR6EB9 | |
| Yamaha | 60 | FT60DETL 4-Stroke | 1995- | 0.9mm (.036") | DPR5EA9 | |
| Yamaha | 60 | T 60 4-Stroke | 2005- | 0.9mm (.036") | DPR6EB9 | |
| Yamaha | 60 | T60 EFI EFI | 2005- | 0.9mm (.036") | DPR6EB9 | |
| Yamaha | 60 | 2-Stroke | 2001-2005 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 70 | 70BETOL 2-Stroke | 1984-2010 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 70 | B | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 70 | BEOL | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 70 | F70AETL 4-Stroke | 2010- | 0.8mm (.032") | LKR7E | |
| Yamaha | 70 | F70AETX 4-Stroke | 2010- | 0.8mm (.032") | LKR7E | |
| Yamaha | 75 | 25AETL 2-Stroke | 1994-1999 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 75 | 75A | 1988- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 75 | A | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 75 | AE | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 75 | AEM | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 75 | AET | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 75 | AM | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 75 | AR | 0.8mm (.032") | B8HS | BR8HS | |
| Yamaha | 75 | F75 4-Stroke | 2003-2005 | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 80 | A | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 80 | AEOL | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 80 | F80BETL 16V 4-Stroke | 1999 2002- | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 80 | F80BETX 16V 4-Stroke | 1999- | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 85 | 85AEDC 2-Stroke | 1989-1996 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 85 | 85AEDX 2-Stroke | 1990- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 85 | 85AETL 2-Stroke | 1989-1996 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 85 | 85AETX 2-Stroke | 1990- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 85 | AE | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 85 | AET | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 90 | 90AETOL 2-Stroke | 2006- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 90 | 90AETOX 2-Stroke | 2006- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 90 | A | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 90 | AEOL | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 90 | F9 4-Stroke | 2003-2005 | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 100 | F100BETL 16V 4-Stroke | 2000- | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 100 | F100BETX 16V 4-Stroke | 2000- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 100 | F100DETL 16V 4-Stroke | 2001- | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 100 | F100DETX 16V 4-Stroke | 1999-2002 | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 115 | 115 CETOL 2-Stroke | 2006- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 115 | 115B | 1.0mm (.040") | BR8HS10 | ||
| Yamaha | 115 | 115C | 1990- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 115 | AE | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 115 | AETOL BETO AET A | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 115 | E115AETL 2-Stroke | 2006-2010 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 115 | E115AETX 2-Stroke | 2006-2010 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 115 | F115AETL 16V 4-Stroke | 2000-2010 | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 115 | F115AETX 16V 4-Stroke | 2001- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 115 | FL115AETX 16V 4-Stroke | 2001- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 115 | V4 | 2000-2005 | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 125 | P125 A | 0.6mm (.024") | B6HS | BR6HS | |
| Yamaha | 125 | P125 AG | 0.6mm (.024") | B6HS | BR6HS | |
| Yamaha | 130 | 130BETOL 2-Stroke | 1990- | 1.0mm (.040") | BR9HS10 | |
| Yamaha | 130 | V 4 | 1988-2004 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 140 | 140B | 1988- | 1.0mm (.040") | BR9HS10 | |
| Yamaha | 140 | BETO | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 150 | 150 FETOL 2-Stroke | 2006- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 150 | 150 FETOX 2-Stroke | 2006- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 150 | 150A | 1988- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 150 | 150C | 1990- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 150 | A | 1986- | 1.0mm (.040") | B8HS10 | BR8HS10 |
| Yamaha | 150 | AETOL | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 150 | F150AETL 16V 4-Stroke | 2004- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 150 | F150AETX 4-Stroke | 2004-2005 | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 150 | FL150AETX 4-Stroke | 2004- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 150 | L 150A | 1988- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 150 | L 150FETOX 2-Stroke | 1990- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 150 | LF 150 | 2004-2005 | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 150 | Z150QETOL HPDI 2-Stroke | 2002- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 175 | VZ175 | 2002-2005 | 0.8mm (.032") | BKR7EKU | |
| Yamaha | 200 | 200A | 1988- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 200 | 200AETL 2-Stroke | 1987-1995 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 200 | 200AETX 2-Stroke | 1987- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 200 | 200B | 1990- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 200 | 200FETOL 2-Stroke | 1999-2005 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 200 | 200FETOX 2-Stroke | 1999-2005 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 200 | 200HP | 2002- | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 200 | A | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 200 | AETOL | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 200 | F200BETX 4-Stroke | 2002-2005 | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 200 | F250DETC 4-Stroke | 2008- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 200 | L 200B | 1990- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 200 | L200 FETOX 2-Stroke | 2005- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 200 | L200AETX 2-Stroke | 1999-2001 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 200 | SX200 4-Stroke | 1999-2005 | 0.8mm (.032") | BR8HS | |
| Yamaha | 200 | VX200 | 2000-2005 | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 200 | VX200D | 2005- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 200 | Z200 F1 | 2002- | 0.8mm (.032") | BKR7EKU | |
| Yamaha | 200 | Z200PETOL HPDI 2-Stroke | 1999- | 1.0mm (.040") | BR8HS10 | |
| Yamaha | 225 | 225A | 1988- | 1.0mm (.040") | BR9HS10 | |
| Yamaha | 225 | 225B | 1990- | 1.0mm (.040") | BR9HS10 | |
| Yamaha | 225 | AETO | 1.0mm (.040") | B8HS10 | BR8HS10 | |
| Yamaha | 225 | F225AETU 4-Stroke | 2005- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 225 | F225AETX 4-Stroke | 2006- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 225 | F225CETL 24V 4-Stroke | 2006- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 225 | F225DETC 4-Stroke | 2002-2005 | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 225 | FL225AETU 4-Stroke | 2005- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 225 | FL225AETX 4-Stroke | 2006- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 225 | Z225HETOL HPDI 2-Stroke | 1997- | 1.0mm (.040") | BR9HS10 | |
| Yamaha | 250 | F250AETU 4-Stroke | 2005- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 250 | F250AETX 4-Stroke | 2003-2005 | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 250 | F250BETU 4-Stroke | 2006- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 250 | F250CETL 4-Stroke | 2005- | 1.1mm (.044") | LFR5A11 | |
| Yamaha | 250 | FL250AETU 4-Stroke | 2005- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 250 | FL250AETX 4-Stroke | 2003- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 250 | FL250BETU 4-Stroke | 2006- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 300 | VZ300 | 2004-2005 | 0.8mm (.032") | BKR6EKU | |
| Yamaha | 300 | Z300 2.3 AETO | 2005- | 0.8mm (.032") | BKR6EKU | |
| Yamaha | 350 | F350AETU 4-Stroke | 2005- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 350 | FL350AETU 4-Stroke | 2005- | 1.1mm (.044") | LFR6A11 | |
| Yamaha | 500 | WJ | 0.7mm (.028") | B7HS | BR7HS | |
| Yamaha | 500 | WR | 0.7mm (.028") | B7HS | BR7HS |
Conclusion
NGK marine spark plugs are a high-quality product that can help keep your boat's engine running smoothly. By following the recommended replacement interval and inspecting your spark plugs regularly, you can help ensure that your boat's engine is getting the spark it needs to perform at its best.
| Model | Type | Year | Gap | Standard | Resistor |
| 1.6 | 1.6 L 115-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 1.8 | 1.8 L 140-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 2 | 1975-1980 | 0.7mm (.028") | B6S | ||
| 2.6 | 2.6 L 190-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 2.7 | 2.7 L 225-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 3.6 | 3.6 L 275-SD | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 4 | CDI | 1987- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| 4 | MAG | 1987- | 0.6mm (.024") | B6HS | BR6HS |
| 4 | 1977-1980 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 4 | 1981-1986 | 0.6mm (.024") | B6HS | BR6HS | |
| 4.5 | 1979-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 6 | 1978-1979 | 0 | BUHW2 | ||
| 6 | 1984-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 7.5 | 1980-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 8 | 1984-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 9.9 | SAIL DRIVE | 1978-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| 9.9 | 1978-1979 | 0 | BUHW2 | ||
| 9.9 | 1980-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 10 | COMMERCIAL | 1981-1982 | 0 | BUHW2 | |
| 14 | COMMERCIAL | 1981- | 0 | BUHW2 | |
| 15 | SAIL DRIVE | 1981-1984 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| 15 | 1978-1979 | 0 | BUHW2 | ||
| 15 | 1980-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 20 | 1985-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 25 | 1978-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 25 | 2003-2005 | 1.0mm (.040") | BPZ8HS10 | ||
| 28 | 1987- | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 30 | 1984-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 35 | 1977-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 40 | COMMERCIAL | 1982- | 0.7mm (.028") | B7HS | BR7HS |
| 40 | COMMERCIAL | 1984-1987 | 0 | BUHW2 | |
| 40 | 1981-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 40 | 1982- | 0.7mm (.028") | B7HS | BR7HS | |
| 40 | 2004-2005 | 0.8mm (.032") | PZFR6H | ||
| 48 | 1987- | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 50 | 1978-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 55 | COMMERCIAL | 1982- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| 55 | COMMERCIAL | 1984-1985 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| 55 | COMMERCIAL | 1986- | 0 | BUHXW1 | |
| 55 | COMMERCIAL | 1987- | 0 | BUHW2 | |
| 55 | 1976-1983 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 60 | 1980-1985 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 60 | 2005- | 0.8mm (.032") | PZFR6H | ||
| 65 | COMMERCIAL | 1984-1986 | 1.0mm (.040") | B9HS10 | BR9HS10 |
| 65 | COMMERCIAL | 1987- | 0 | BUHW2 | |
| 70 | 1975-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 75 | HUSTLER | 1975- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| 75 | 1976-1985 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 75 | 2001-2005 | 0.8mm (.032") | BKR5EK | ||
| 85 | 1975-1980 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 90 | 1981-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 90 | 2001-2005 | 0.8mm (.032") | BKR5EK | ||
| 90 | V4 FFI | 2000- | 0.8mm (.032") | PZFR6H | |
| 100 | COMMERCIAL | 1984- | 0 | L76V | |
| 100 | COMMERCIAL | 1985-1987 | 0 | BUHW2 | |
| 100 | 1979-1980 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 100 | 2004-2005 | 0.8mm (.032") | BKR5EK | ||
| 110 | 1986-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 115 | E-TECH | 2005- | 0.8mm (.032") | IZFR5J | |
| 115 | 1975-1984 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 115 | 1985- | 0 | L76V | ||
| 115 | 2004-2005 | 0.8mm (.032") | BKR5EK | ||
| 120 | 1985-1987 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 125 | COMMERCIAL | 1990- | 1.0mm (.040") | B9HS10 | BR9HS10 |
| 140 | 140 S | 1977-1979 | 0 | BUHXW1 | |
| 140 | 1973-1984 | 0 | BUHXW1 | ||
| 140 | 1985-1992 | 1.0mm (.040") | BR9HS10 | ||
| 150 | 1978-1987 | 0 | BUHXW1 | ||
| 150 | 1988-1992 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 155 | COMMERCIAL | 1978-1986 | 0 | BUHXW1 | |
| 155 | COMMERCIAL | 1987- | 0 | BUHW2 | |
| 155 | COMMERCIAL | 1989-1992 | 0 | BUZ8H | |
| 175 | 1977-1987 | 0 | BUHXW1 | ||
| 175 | 1988-1992 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 175 | 2005- | 0.8mm (.032") | IZFR5J | ||
| 185 | COMMERCIAL | 1984-1985 | 0 | BUHXW1 | |
| 185 | COMMERCIAL | 1990-1992 | 1.0mm (.040") | BR9HS10 | |
| 200 | F MODELS | 2005- | 0.8mm (.032") | PZFR6H | |
| 200 | F MODELS | 2005- | 0.8mm (.032") | PZFR6H | |
| 200 | F MODELS | 2005- | 0.8mm (.032") | PZFR6H | |
| 200 | 1976-1983 | 0 | BUHXW1 | ||
| 200 | 1986-1992 | 1.0mm (.040") | B9HS10 | BR9HS10 | |
| 225 | F MODELS | 2005- | 0.8mm (.032") | PZFR6H | |
| 225 | 1986- | 1 | B9HS10 | BR9HS10 | |
| 235 | 1978-1985 | 0 | BUHXW1 | ||
| 250 | F MODELS | 2005- | 0.8mm (.032") | PZFR6H | |
| 250 | 1991-1992 | 1 | BR9HS10 | ||
| 275 | 1985-1988 | 1 | BR9HS10 | ||
| 300 | 1986-1992 | 1 | B9HS10 | BR9HS10 |
